Advantages
Digital microphones with active noise cancellation for noisy work environments
Clear, well arranged operation through high-resolution microdisplay
Powerful 48 MP camera with outstanding recording quality for optimum documentation in both still and moving images
Teledyne FLIR Thermal Camera Module for radiometric photos, built-in to the image.
More features
Amplified loudspeaker
Available languages: German, English, French, Spanish, Italian, Portuguese, Chinese, Turkish, Czech, Dutch, Russian, Norwegian, Danish, Polish, Indonesian, Japanese, Korean, Thai
Approvals
ATEX (Europe) approved
I M1 Ex ia I Ma
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T200°C Db
IECEx (International) approved
Ex ia I Ma
Ex ib IIC T4 Gb
Ex ib IIIC T200°C Db
UKEX (United Kingdom) approved
I M1 Ex ia I Ma
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T200°C Db
QPS (Northern America) approved
Class I Div. 1 Groups A, B, C, D, T4
Class II Div. 1 Groups E, F, G, T200 °C
Class III
IA (South Africa) approved
EX ia I Ma
Ex ib IIC T4 Gb
Ex ib IIIC T200°C Db
INMETRO (Brasil) approved
Ex ib IIC T4 Gb
Ex ib IIIC T200°C Db
PCEC (China) approved
Ex ib II C T4 Gb
Ex ib IIIC T200°C Db
TIIS (Japan) approved
Ex ib IIC T4 GbEx ib IIIC T200°C Db
KCs (South Korea) approved
Ex ib IIC T4 Gb
Ex ib IIC T200°C Db
Included
REALWEAR NAVIGATOR Z1
Battery
i.safe PROTECTOR 2.0
Carrying Case
Tri-Band Strap REALWEAR NAVIGATOR Z1
Screwdriver
Safety Instructions
- Dimensions
Weight: 383 g - Sampling rate
8,7 Hz - Interfaces
earphone jack | USB-C - Battery
2550 mAh, 3,7 V | replaceable - Operating system
Android™ 12 (AOSP) + WearHF™ hands-free interface - Camera
48 MP AF front - Processor
Qualcomm® QCS6490 - Types of protection
IP66 | MIL-STD 810H | Usable from -20 °C to +55 °C - Sensor type
FLIR Lepton® 3.5 - Field of view (DFOV) °
71 - Field of view (HFOV) °
57 - Memory
8 GB RAM | 128 GB internal memory - Spectral range
8 – 14 - Temperature detection from (°C)
-10 - Temperature detection up to (°C)
400 - Temperature accuracy
±5 °C oder 5 % (typisch) | ±10 °C oder 10 % (typisch) - Thermal resolution
160 x 120 - Thermal Sensitivity
<50 mK - Connectivity
| Bluetooth® 5.2 | GPS, Glonass, Beidou, Galileo, NavIC, QZSS, SBAS - Video (pixel & bitrate)
1080 p @ 60 fps - Anschlussmöglichkeiten (Kopfhörer, USB, Zubehör, …)
earphone jack
