Advantages
Capture, analyze and document thermal images
Direct data transfer via multifunctional (ISM) interface
Direct interface connection with the device, no Bluetooth® necessary
Power supply via the connected device, therefore no battery necessary
More features
Power supply over the connected mobile device
Approvals
ATEX (Europe) approved
II 2G Ex ib IIC T4 Gb
II 2D Ex ib IIIC T135°C Db
IECEx (International) approved
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db
NEC500 (North America) approved
Class I Div. 1 Groups A, B, C, D, T4
Class II Div. 1 Groups E, F, G, T135°C
Class III Div. 1
INMETRO (Brazil) approved
Ex ib IIC T4 Gb
Ex ib IIIC T135°C Db
Included
Thermal camera
Quick Start Manual
Safety Instructions
- Sensor resolution
200 (h) x 150 (v) | 30000 pixel | FixFocus | Digital zoom via App - Sensor sensitivity
65 mK (typical) - Frame rate
<9 Hz bis 32 Hz - Scene dynamic range
-40 °C bis 330 °C - Temperature accuracy
±7 °C and 7 % (at 5 °C to 140 °C) | ±10 °C and 10 % (at 140 °C to 330 °C) - Field of view
35° (HFOV) | 26° (VFOV) - Detection range
up to 300 m - Recognition range
up to 75 m - Identification range
up to 25 m - Dimensions
Size: 112,0 x 82,0 x 50 mm | Weight: 195 g - Types of protection
IP68 dust-/waterproof | MIL-STD 810H | Usable from -20 °C to +55 °C
